Liquid

IODINE PT/CO SAYBOLT GARDNER ASTM D 1500
Assured colour quality in production environments
Reproducible colour values are an important factor in quality assurance, e.g. dye, paint industries and the petrochemical sector. LICO 150 is a portable colorimeter.
Its high quality optical system ensures exact and reproducible measured values.
Once a value has been measured on site, it can be called up at any time in all five ISO/ASTM colour scales.
The colorimeter is designed to offer maximum handling in production environments.
With intuitive input via a touchscreen, calibration memory for every type of cuvette, and data storage
capacity for 200 measurements.
LICO 150 can be fitted with a powerful lithium battery for on-site use.
Simple: large touchscreen with intuitive user guidance
Error-safe: reference beam technology and cuvette identification
Reliable: automatic calibration reminder and self-testing
Portable: optional battery allows the colorimeter to be used anywhere
Operating mode : Colour measurement of optically clear liquids
Colour value system : DIN 6162 iodine colour value
ISO 6271 Pt/CO- (Hazen, APHA) colour value
ISO 4630 Gardner colour value
ASTM D 156 Saybolt colour value
ASTM D 1500 Mineral oil colour value
Wavelength range : 400–700 nm in 20 nm steps
Photometric accuracy : 5 mAbs from 0.0 to 0.5 Abs; 1 % at 0.5 to 2.0 Abs
Beam path : Halogen lamp 6 V / 10 W, reference beam technology
Cuvette sizes : 11 mm round, 10 mm and 50 mm rectangular
Cuvette identification : Automatic with calibration memory
Display : High resolution 5.7 inch LCD touchscreen (320 × 240 pixel)
Data storage : 200 measured colour values
Ports : 1 × USB type A for memory stick, printer, keyboard, barcode scanner
1 × USB type B for PC
Ingress protection rating : IP 41
Power requirement : 100–240 V, 47–63 Hz, 30 VA
Battery (optional) : Lithium, 11 V, 4,400 mAh, for at least 300 measurements in 8 hours
Dimensions, weight : (W × H × D) 220 × 135 × 330 mm; 4 kg
